Pistols, revolvers, rifles, and shotguns.

TM 746-10

cushioning. Position tripod over the legs.

munition chests in two packages (two per package),

wrap in waterproof barrier, and secure with tape. Place

(3) Receiver, radar test, and cable assembly.

the chests in the gunner's compartment of the mount.

Wrap receiver in greaseproof barrier material and

5 Battery cables. Preserve cable

overwrap with cellulosic cushioning. Unit pack receiver

ends with P-ll, wrap in greaseproof barrier material, and

submethod IC-1. Place bag in a fiberboard box lined

secure with tape.

with a 1-inch minimum thickness of bound fiber. Also,

place cable in box and seal with tape.

6 Mount.

Preserve unpainted

surfaces with P-ll, wrap preserved surfaces with

(c) Microphone assembly.

Wrap

greaseproof barrier material, and secure with tape.

microphone in neutral barrier material and secure with

tape. ace microphone in a fiberboard box and seal all

7 Overall cover. When an overall

openings with tape (fig 4-3). Place box in provided

cover is available, place it over the entire mount and

cushion cavity of the accessory box.

secure it in place with ties provided. When a cover is

not available, shroud the entire mount with polyethylene

(d) Telescope, XM28 with case. Place

film and secure in place with tape.

telescope in its carrying case and place the case in

provided cushion cavity of the accessory box.

t. Pistols, revolvers, rifles, and shotguns.

addition to process C-3, clean weapons with rifle bore

(e) Light instrument, M53E1, bracket

cleaner followed by a solvent wash. Preserve entire

and clamp. Remove batteries and throw away. Wrap

weapon per paragraph 4-101d. Unit pack wrapped

bracket with neutral barrier material and secure with

weapon submethod IC-1. Place one or more weapons

tape. Secure wrapped bracket to light instrument and

in fiberboard, wood, or plywood boxes. When more

coil cable around light. Position in the provided cushion

than one weapon is packed in a box, separate weapons

cavity of the accessory box.

by using bound fiber or fiberboard sheet stock. Seal all

(f) Chronograph automatic reliability

openings with tape (fig 4-3).

rotor. Place in provided cushion cavity of the accessory

u. Plotting boards. No preservative is required.

box.

Place one plotting board between two pieces of

(g) TMs and log book.

Stow in

fiberboard sheet stock and secure fiberboard together

available space adjacent to tripod.

with tape. Unit pack plotting board, carrying case, and

(h) Cable assembly.

Place in its

manual using submethod IC-3. Place a quantity of

carrying case, close cover, and locate in the tripod area.

packed items in a fiberboard box and seal with tape.

(i) Accessory box.

Close box and

v. Quadrant, gunners and elevation. Preserve

secure all latches. Provide security seals on at least

unpainted surfaces with P-7. Close level vial cover.

three latches.

Wrap entire quadrant in greaseproof barrier and secure

(3) Cable and reel assembly (box 3 of 4).

with tape. Preserve mounting hardware with P-7 and

Place item in a wood box. Immobilize contents by

unit pack submethod IC-1.

Place quadrant and

placing four vertical wood blocks in the box corners.

hardware in a fiberboard box, fill void with cellulosic

Nail all blocking securely (fig 4-2).

cushioning, and seal with tape.

(4) Bracket installation jeep mounting (box 4

w. Radar chronograph, M36. No preservative is

of 4). Place item in a wood box. Unit pack installation

required. Use reusable containers whenever possible

drawing submethod IC-1. Secure bag to the item inside

and retain for reuse. When reusables are not available,

box with tape.

substitute wood or plywood boxes. Use polyethylene

x. Rangefinders.

foam as interior container cushioning. Pack radar

chronograph in a set of four boxes.

(1) Disassembly. Disassemble end housing

assemblies from center housing assemblies on the M13

(1) Radar chronograph with mount (box 1 of

and M17 series. Support legs with tape. Remove tape

4). Attach the mount to radar chronograph and lock.

when ready to place support legs in reusable container.

Position in the lower cushion cradle assembly of the

reusable container. Position upper cradle assembly

(2) Cleaning and drying.

Clean and dry

over chronograph and secure with straps provided.

optical portions per paragraph 4-101.

Position container cover on body of container, alighing

(3) Mounting hardware. Wrap all mounting

arrows on exterior surfaces. Close and install security

hardware together in greaseproof barrier material and

seals on the four container latches.

unit pack submethod IC-1. Attach bag to rangefinder

(2) Accessory equipment (box 2 of 4).

with tape.

(a) Tripod assembly. Locate the three

(4) Packaging.

auxiliary tripod legs on the bottom of the container

(a) Cover critical mating surfaces of the

4-36

TM 746-10
